The Gabriel 85084 FleetLine 85 Series is a rugged, heavy-duty shock absorber engineered specifically for Class 6-8 trucks and trailers. Designed as a direct OE replacement, it features a 1-5/8" bore and 10-stage valving to compensate for suspension softening and restore original ride control.
Key Features
- ♦Enhanced Durability: Large 1-5/8” bore provides superior tensile strength for harsh operating conditions.
- ♦Superior Sealing: Multi-lip piston rod seal and pressurized piston ring reduce friction and self-compensate for wear.
- ♦Structural Integrity: 360° arc-welded end mounts deliver exceptional strength to prevent mount failure.
- ♦Hydraulic Stop: Best-in-class hydraulic rebound stop prevents the shock from topping out or overextending the suspension.
Technical Specifications
| Attribute | Specification |
|---|---|
| Extended Length | 20.59 in |
| Collapsed Length | 13.03 in |
| Stroke | 7.57 in |
| Bore Size | 1-5/8 in |
| Mounting (Upper/Lower) | ES174 / ES136 |
Compatibility
- Kenworth: T270 (2008-2022), T370 (2008-2022), T680 (2013-2024)
- Peterbilt: 579 (2013-2024), 567 (2014-2024), 587 (2011-2018), 382 (2011-2017)
- Other: Also fits various Peterbilt 325, 337, 348, and 548 models.
OEM Cross-Reference
Replaces: Peterbilt B71-6004, B71-6005, B71-6006 | Monroe 65175, 65176 | Dayton M65175 | ACDelco 519-32 | FCS F347249
